GENESIS SERIES
GENESIS SERIES
The Cast Genesis Series offers models with hydrostatic transmission 4WD. The hydraulic force discharged on the ever-active wheel engines ensures a good compromise between economy and power with excellent performance under all conditions, even on terrain where the grip may not be optimal. This machine is equipped with quick couplings and a universal mini plate to make the job quick, easy and practical.
GENESIS SERIES STANDARD FEATURES
GENESIS 25HP
Hydrostatic Transmission (4WD)
Mechanical Differential Lock
Liquid Cooling
Self-Leveling
12 V Power Outlet
Front LED Lights
Universal Coupling Plate
Telescopic Boom
ROPS/FOPS Protection
Ergonomic Seat
Front/Rear Metal Hoods
TIGHT TURNING RADIUS
GENESIS 40XD
Cabin with Heat & AC
Hydrostatic Transmission (4WD)
Electric Differential Lock
Liquid Cooling
Double Cylinder Hydraulic Self-levelling
Universal Coupling Plate
Telescopic Boom
Working LED lights (2 front + 1 rear)
12 V Power Outlet + 165 W Front Auxiliary Electric Outlet
Ergonomic Seat
Front/Rear Metal Hoods
Soundproof Cabin
Front LED Lights
ROPS/FOPS Protection
Driving Lights
Rear View Mirrors
Rear Counterweights
Reverse Alarm
Tie Down Lugs
Toro Plate
Roof with Sunshade
Mechanical 4 Wheel Steer
TIGHT TURNING RADIUS
GENESIS SERIES OPTIONS
| OPTIONS | Part# | Available Models |
|---|---|---|
| Electric Floating System | 45120355 | All Models |
| Anti-Skid | 45120032 | All Models |
| Rear 3 Point Set-up for Lifter (Double Flow) | 45120147 | All Models |
| Independent Rear Outlet + 15 Function Joystick | 45120338 | All Models |
| Trailer Coupling for 210Kg Rear Counterweights | 45120027 | All Models |
| Quick Coupling System "MULTIFASTER"® Part Fixed on the Machine | 45120128 | All Models |
| Quick Coupling System "MULTIFASTER"® Part for the Attachments | 45120312 | All Models |
| Heated Fabric Seat | 45120144 | All Models |
| Mechanical Suspension for Adjustable Ergonomic Seat | 45120211 | All Models |
| Pre-Heating of Engine's Water | 45120129 | All Models |
| Rear Auxiliary Electric Outlet 165W | 45120010 | All Models |
| Cylinders with Anti-Fall Valve | 45120041 | All Models |
WHEEL OPTIONS
TRACTOR
29x12.50-12
31x15.50-15 Offset 55
ALL TRAC
31x15.50-15
TURF
29x12.50-15
31x15.50-15
CAST GENESIS 25HP
The Cast Genesis 25HP is the economical option in the Genesis series that still packs a big punch. The 25 HP Yanmar engine and 11 GPM hydraulic system offers operators an impressive 2653 lbs lifting capacity, 1485 lbs breakout force and 1650 lbs max pulling force. The Genesis 25HP comes standard with a 4WD hydrostatic transmission, a mechanical differential lock, liquid cooling and self-levelling feature.
LIFTING CAPACITY
2653 lbs
BOOM HEIGHT
108 in
ENGINE POWER
25 HP
HYDRAULIC SYSTEM
11 GPM
| Breakout Force with Boom Down | 1485 lbs |
| Average Sound Power Level (dB/LwA) | 99 |
| Guaranteed Sound Power Level (dB/LwA) | 101 |
| Engine Oil Tank Capacity (G) | 1.1 |
| Hydraulic Oil Tank Capacity (G) | 7.9 |
| Weight | 2756 lbs |
| Cab (Genesis 25HP, Genesis 40XD) | Open Station |
| Cab (Genesis 25HPC, Genesis 40XDC) | Enclosed Glass Cab with Heating System |
SPECIFICATIONS
| Engine | Yanmar 3TNV80 |
| HP | 25 |
| Speed Km/h | 12 |
| GPM | 11 |
| Joystick | 5 Function |
| Wheels | 23×10.50-12 |
| Lifting Capacity | 2653 lbs |
| Tipping Load in Transport Position | 1540 lbs |
| Max Pulling Force | 1650 lbs |
CAST GENESIS 40XD
Genesis 40XD was born from the evolution of the proven 45T model and today represents the best solution for the demanding professional. The 4-wheel drive are steered and offer extraordinary maneuverability especially in small spaces. The interiors are comfortable and offer full instrumentation with a latest generation electronic display. The adjustable and comfortable seat is complete with armrest and seat belts. The cabin is soundproof and can be equipped with heating and air conditioning.
LIFTING CAPACITY
4409 lbs
BOOM HEIGHT
130 in
ENGINE POWER
38 HP
HYDRAULIC SYSTEM
17 GPM
| Breakout Force with Boom Down (lbs) | 3307 |
| Average Sound Power Level (dB/LwA) | 99 |
| Guaranteed Sound Power Level (dB/LwA) | 101 |
| Engine Oil Tank Capacity (G) | 1.3 |
| Hydraulic Oil Tank Capacity (G) | 18.5 |
| Weight | 4630 lbs |
| Cab (Genesis 25HP, Genesis 40XD) | Open Station |
| Cab (Genesis 25HPC, Genesis 40XDC) | Enclosed Glass Cab with Heating System |
SPECIFICATIONS
| Engine | Yanmar Stage V |
| HP | 38 |
| Speed Km/h | 16 |
| GPM | 17 |
| Joystick | 11 Function |
| Wheels | 29×12.50-15 |
| Lifting Capacity | 4409 lbs |
| Tipping Load in Transport Position (lbs) | 3307 [A] |
| Max Pulling Force (lbs) | 2778 @ 29x12.50-15 |
